120A Ground Waterproof Brushless Motor Speed Controller (ESC) Leopard Hobby

Features:

• Completely water-proof and dust-proof.

• Easily programmed with the SET button, LED Program Box, Multifunction LCD Program Box and USB Link Software.

• Electric brake function, also compatible with mechanical disc-brake system.

• ESC firmware can be updated through the USB adapter in the LCD Program Box.

• Excellent start-up, acceleration and linearity features.

• Internal timing can be changed easily to make the ESC suitable for various of motors.

• Mounting stand for installing the ESC on chassis easily and firmly.

• Multiple protection features: Low voltage cut-off protection / Over-heat protection / Throttle signal loss protection.

• Plenty of programmable items, suitable for various of chassis's, tires and racing tracks.

• Powerful built-in switching mode BEC.

• Special program port for easily setting the ESC.

Specifications:

Output: Continuous 120A, burst 760A;

• Input: 6-12 cells NiMH/NiCd or 2-4S Lipo;
• BEC Output: 6V/3A (Linear mode built-in BEC)
• Resistance: 0.0004 Ohm;
• Motor Supported: Sensorless Brushless Motor;
• Suitable Brushless Motor:

1. With 6 cells NiMH/NiCd or 2S Lipo: KV≤6000;
2. With 7-9 cells NiMH/NiCd or 3S Lipo: KV≤4000;
3. With 10-12 cells NiMH/NiCd or 4S Lipo: KV≤3000;

• Suitable Car: 1/10 4WD SCT, 1/8 2WD and 4WD buggy/SCT (Include TRAXXAS 1/10 SCT);
• Size: 59mm(L) * 38mm(W) * 34mm(H);
• Weight: 113g

Ground-WP-SC8 Data Sheet
