Molex Micro Spox 2 pin connector - Male

Features:

• 2 circuits
• Very low profile
• Molded-in pull tabs
• Friction lock

Specifications:

• 2.5mm pitch
• Electrical Voltage: 250V
• Current:
• 22Awg → 3A
• 24awg → 2.5A
• 26Awg → 2A
• 29awg → 1.5A
• Contact Resistance: 20mΩ max.
• Dielectric Withstanding Voltage: 1000V AC/1 min.
• Insulation Resistance: 1000 MΩ min.
• Physical Housing: 6/6 nylon, UL 94V-0
• Operating Temperature: -40 to +105˚C
