Miniature toggle switch - Single pole
Single pole change over (SPCO)
Rugged and reliable miniature toggle switches, with a long mechanical and electrical life cycle.
| Rating: | 5A 120VAC / 2A 240VAC / 5A 28V dc |
| Dielectric strength: | 1500V AC / 1 min. |
| Contact resistance: | <10MΩ max initial. |
| Mechanical life: | >100,000 cycles |
| Electrical life: | >50,000 cycles at full load |
| Contacts: | Silver plated. |
| Dimensions: | SPST: 8.89mm H x 12.7mm W x 6.87mm D |
| Panel cutout: | 0.25" / 6.35mm |
| SKU | SW301 |
|---|---|
| Colour | Black |
